Huawei Power-M 6kVa Power Module Inverter + 5kWh Battery

₦2,398,000

Power Inverters

Fulfilled by: Zit

Quantity:

View Cart

Product Description

FEATURES

Excellent performance:
Ultra-fast: 3-hour fast charge 100%
Ultra-quiet: Fan less design, operating noise less than 29 dB
Energy switchover without perception<10ms
Smart priority management (Solar /battery /grid /DG)
Smart mobile APP management: monitor device running status in real time, help EPC & client efficiently manage device.
D.G. scheduling is supported, D.G. does not need to be started manually.
Built-in energy optimizer, supporting mixed use of old and new lithium batteries
5Years Warranty

Huawei Power-M 6kVa Power Module Inverter + 5kWh Battery

HUAWEI

Description

For technical inquiries, please reach out to¬†solar@fouani.com

Comes with 1 battery, can take up to 3 batteries (5kWh each) to become 15kWh

Excellent performance:
Ultra-fast: 3-hour fast charge 100%
Ultra-quiet: Fan less design, operating noise less than 29 dB
Energy switchover without perception<10ms
Smart priority management (Solar /battery /grid /DG)
Smart mobile APP management: monitor device running status in real time, help EPC & client efficiently manage device.
D.G. scheduling is supported, D.G. does not need to be started manually.
Built-in energy optimizer, supporting mixed use of old and new lithium batteries

Secure and Reliable:
90‚Äì300 V, withstand voltage jump
1.5 times the shock of the device startup current (air conditioner, washing machine, and motor)
0 Second Fast shut down (solar PV modules‚Äô voltage can be quickly shut down to 0 V within 0sÔºåEnsure the safety: the owner, installation and maintenance personnel)
IP65 dustproof & waterproof ( indoor /outdoor)
Matrix Design Heat Dissipation
AFCI function
Most stable LFP Battery, no fire risk
Battery built-in full-dimensional high-precision sensors¬†

Comes with 1 battery, can take up to 3 batteries (5kWh each) to become 15kWh

Power ModuleISitePower-M-MAP05A1

Output/Input Power Per Module2.5kW

Battery Module Capacity5kWh

Battery ModuleISitePower-M-MAB05B1

DisplaySOC Status IndicatorCommunicationCAN (For Parallel Communications), WLAN/FE/4G (For The SmartPVMS)Power Module Dimensions (WxHxD)700mmx246mmx152mmPower Module Weight17KGBattery Module Dimension (WxHxD)700mmx390mmx158mmBattery Module Weight50KGBase Dimension (WxHxD)700mmx65mmx147mm (Floor Installed) And 643mmx110mmx176mm (Wall-Mounted)Base Weight1.5KG (Floor Installation) / 5.5KG (Wall-Mounted)IP RatingIP66Cell TechnologyLithim-Iron Phosphate (LiFePO4)Input Voltage200/208/220/230/240V ACInput CurrentMax.30AFrequency50/60HzMaximum Bypass Input Power6kW
