Pure Sine Wave Solar Inverter is a next generation solar inverter, that is easy to install, highly efficient and has a sleek artistic design.

FEATURES

• Solar /AC Inputpriority via LCD setting
• Selectable charging current, O/P Volatage and O/P frequency
• Solar inverter 5kw can run 3HP Air conditioning , 3Kw for 2HP and 2KW for 1HP
• parallel function availab;e for 4kw/5kw inverter

Model name; PV 1800

MD; PV 18-5048 VHM

Operating temperature Range 10C-50C

Protection Class: Class I

Rated Power : 5000VA/5000W

DC Input: 48VDC,118A

AC Output:230VAC,50Hz, 22A,

AC CHARGER MODE:

AC Input 230VAC, 50Hz, 35A

DC Output: 54VDC ,60A{Max}

Solar Charge Mode:

Rated current 80A

System Voltage: 48VDC

MPPT Volatage range: 60-130VDC

Max Solar Voltahe {VOC}: 145VDC

MAX. Charge Current: 140A
