Product description
FEATURES
- Rechargeable Lithium Ion Battery 3552
- Wh 48Vdc 74Ah,
- 95% DOD,
- 442*410*132 mm,
- 32 kg,
- Single string quantity 16 units,
- Cycle life > 8,000
- 5 years warranty


Discover the Pylontech US3000C, a state-of-the-art HESS solar battery system developed by Pylontech, featuring their cutting-edge lithium iron phosphate cells. With a strong commitment to safety and performance, the US3000C is engineered to provide a secure and efficient energy storage solution for your home. It comes equipped with a self-designed Battery Management System (BMS) that safeguards against abnormal temperature, current, voltage, State of Charge (SoC), and State of Health (SoH).Why Choose the Pylontech US3000C?
Impressive Power Output: With the capability to deliver up to 3.5kW* from a single module (3.5kWh), the US3000C offers a high level of performance. Please note that the actual power output may vary depending on your inverter/charger, but typically, it sustains a maximum of 1.8kW per battery.
Modular Design: The US3000C’s modular design allows you to choose the capacity that aligns with your energy requirements, giving you the flexibility to customize your energy storage system.
Hybrid Inverter Compatibility: This battery is compatible with a large number of hybrid inverters, ensuring seamless integration into your existing energy setup.
Easy Installation: Featuring a simple buckle fixing system, the US3000C minimizes installation time and cost, making it a hassle-free addition to your energy ecosystem.
Surge Current Protection: The US3000C provides a pre-charge function, safeguarding your Energy Storage System (ESS) from surge currents and enhancing the longevity of your setup.
Scalability: You can stack up to 16 units of the US3000C in parallel, offering you the flexibility to expand your energy storage as needed.
Specs
Specs
| Nominal Voltage (Vdc) | 48 |
| Nominal Capacity (KWh) | 3.55 |
| Usable Capacity (KWh) | 3.37 |
| Dimension (Mm) | 442x410x132 |
| Weight (Kg) | 32 |
| Charge/Discharge Current (A) (Recommended) | 37 |
| Charge/Discharge Current (A) (Max Continuous) | 37 |
| Charge/Discharge Current (A) (Peak 1) | 74-89 @ 60sec |
| Charge/Discharge Current (A) (Peak 2) | 90-200 @ 15sec |
| Communication Port | RS485,CAN |
| Single String Quantity (Pcs) | 16 |
| Working Temperature (C) (Charge) | 0-50 |
| Working Temperature (Discharge) (Charge) | -10-50 |
| Shelf Temperature (C) | -20-60 |
| Short Current/Duration Time | <4000A/2ms |
| IP Rating | IP20 |
| Cooling Type | Natural |
| Humidity | 5%-95% (RH) No Condensation |
| Altitude (M) | <4000 |
| Design Life | 15+ Years (25 Degrees C) |
| Cycle Life | >8,000 (25 Degrees C) |
| Certification | UL1973, UL1642, UL9540A, VDE2510-50, IEC63056, IEC62619, IEC62040, IEC62477-1, ICE61000-6-2, UN38.3 |
